Mother and Child Shuttle
The mother-daughter shuttle is an intelligent handling device in one automated storage flow system. With the characteristics of dynamic transfer, it can make the transportation layout of items between various shelves more compact and simple, thereby improving the transportation efficiency of items. High degree of automation and flexibility. The sub-mother shuttle is composed of two-way sub-shuttle and mother shuttle, as well as tracks, walking roadways, goods roadways, track-through dense shelves, reciprocating lifts, layer change hoists, outbound conveyor lines, inbound conveyor lines, and computer control systems.
key word:
Product classification:
Product description
The scope of application of the mother-child shuttle
The sub-mother shuttle is suitable for the transfer and transportation of various palletized goods, and is widely used in warehouses, warehousing and logistics centers, and is most common in dense three-dimensional warehouses.
The basic working principle of the mother-child shuttle
The mother-child shuttle can be said to be the mother car leading a series of sub-cars on the main road of the warehouse. When a designated branch road is reached, the sub-car can be automatically released and then independently operated to work on the branch road. The mother car continues to drive forward in this link, and the storage link saves a lot of time and greatly promotes work efficiency.
Related products
Main functions of the stacker: In fact, this kind of equipment is a kind of storage and delivery equipment in an automated three-dimensional warehouse, usually divided into single column and double column structures. The overall use requirements are achieved through walking, lifting, and other mechanisms. In addition, advanced servo control systems and certification systems perform fully closed loop control, and the use of high-precision address recognition such as barcode or laser ranging can enable the equipment to operate with high accuracy. It is also a lifting device used for forks to access goods from high-rise shelves. The warehouse using this device can reach about 45 meters, and the stacker can operate in the passageway between the shelves and handle items loaded on or toward the pallets. Characteristics of the stacker: 1. Structural characteristics In terms of structure, it has different structures such as single column and double column, and there are also two types of cargo forks: European standard cargo forks and Japanese standard plate forks. The former corresponds to crossbeam type shelves, while the latter corresponds to bracket type shelves. This type of equipment can greatly improve the use area and space utilization rate of the warehouse, reduce manual operations, and improve the overall warehousing operation effect and automation level. 2. Usage characteristics The equipment can be divided into straight track type, curved track type, transition track type, and fork track type according to the direction of the channel. In addition, there is a selection type equipped with a cab. Its structure is very stable and reliable, and it is controlled through vector frequency conversion drive and encoder position. The use of mechanical and electrical dual protection devices to ensure safety, coupled with information transmission and full tracking technology, effectively improves the overall equipment function. Imported electrical components, The fake face operation of the touch screen not only makes the operation simpler, but also provides time manual, click automatic, and online automatic control effects.
This product is in line with international standards, with the same indicators, functions and performance as international products, and can be used for export products. The research and development of light four-way shuttle makes up for the multi-dimensional defects of the current two-way shuttle movement
Shuttle truck three-dimensional warehouse is a high-density automatic storage system composed of shelves, shuttle trucks, and forklifts, which can achieve semi-automatic operations.
The mother-daughter shuttle is an intelligent handling device in one automated storage flow system. With the characteristics of dynamic transfer, it can make the transportation layout of items between various shelves more compact and simple, thereby improving the transportation efficiency of items. High degree of automation and flexibility. The sub-mother shuttle is composed of two-way sub-shuttle and mother shuttle, as well as tracks, walking roadways, goods roadways, track-through dense shelves, reciprocating lifts, layer change hoists, outbound conveyor lines, inbound conveyor lines, and computer control systems.
There are two main forms of shuttle vehicles in warehousing and logistics equipment: shuttle vehicle type inbound and outbound systems and shuttle vehicle type warehousing systems. They are trolleys that operate on fixed tracks in a reciprocating or looping manner to transport goods to designated locations or connecting equipment. Equipped with an intelligent sensing system, it can automatically memorize the origin position and automatically decelerate the system.
